Product description

Equipped with advanced imaging features such as Backlight Compensation, Digital Wide Dynamic Range, and Samsung Super Noise Reduction, the SCV-6085R ensures the capture of clear, detailed images under any lighting conditions. The camera's infrared LEDs allow for up to 30 m of visibility in complete darkness, ensuring reliable surveillance around the clock. Additionally, its support for both AHD and composite video signals provides flexible integration options with existing surveillance systems, making it a versatile choice for a wide range of security needs.

Product features

Wide angular field of view
With an angular field of view ranging from 36.6 to 128.4 degrees, the Hanwha Vision WiseNet HD+ SCV-6085R offers expansive coverage, making it suitable for monitoring large areas with fewer cameras.
Exceptional low-light performance
Equipped with infrared LEDs and a minimum illumination of 0 lux in B&W mode, this surveillance camera ensures clear, detailed images even in complete darkness, up to a distance of 30 m.
Durable and resilient
Designed to withstand harsh environmental conditions, the SCV-6085R is compliant with IK10 and IP66 standards, ensuring protection against vandalism and the elements.
Advanced imaging features
Features such as Backlight Compensation (BLC), Digital Wide Dynamic Range (D-WDR), and Samsung Super Noise Reduction (SSNRIV) work together to deliver crisp, clear images in any lighting condition.
Versatile connectivity
Supporting both AHD and composite video signals, this camera offers flexible integration options with existing surveillance systems, ensuring high-quality video capture and easy setup.

General

Brand

Hanwha Techwin

Manufacturer

Hanwha Vision

Model

SCV-6085R

Packaged Quantity

1

Product Line

Hanwha Vision WiseNet HD+

Dimensions & Weight

Depth

13.7 cm

Height

10.61 cm

Weight

715 g

Width

13.7 cm

Lens System

Angular Field of View (D, max, degree)

128.4

Angular Field of View (D, min, degree)

36.6

Angular Field of View (H, max, degree)

110.2

Angular Field of View (H, min, degree)

32

Angular Field of View (V, max, degree)

55.4

Angular Field of View (V, min, degree)

18

Auto Iris Control

DC

Focal Length Control

Vari-focal

Lens Iris

Auto iris

Miscellaneous

Color Category

White

Optical Sensor

Sensor Size

1/2.8"

Sensor Size (metric)

9.1 mm (1/2.8")

Total Pixels

2,000,000 pixels

Surveillance Camera

Indoor / Outdoor

Outdoor

Video Input

Camera Mechanical Design

Fixed

Camera Type

Surveillance camera

Connectivity Technology

Wired

Day & Night Functionality

Yes

Form Factor

Dome , Dome

Frame Rate (max)

30 frames per second

Max Digital Video Resolution

1920 x 1080

Motion Detection

Yes

Supported Video Signals

Composite video , AHD

Data sheets / Brochures

Data sheet / Brochure 1
